GIGABYTE AORUS 17 (2023) BSF-73SG654SH

Production Specification

OS

Windows 11 Pro (GIGABYTE recommends Windows 11 Pro for business.)
Windows 11 Home
No preinstalled OS

CPU

13th Gen Intel® Core™
i7-13700H Processor 5.0 GHz (24MB Cache, up to 5.0 GHz, 6 P-cores and 8 E- cores)

Video Graphics

Intel® Iris Xe Graphics,
NVIDIA® GeForce RTX™ 4070 Laptop GPU 8GB GDDR6
Boost Clock 2175 MHz / Maximum Graphics Power 140W
*May vary by scenario.

Display

17.3″ 16:9 Thin Bezel QHD 2560×1440, 240Hz, up to 100%sRGB, TÜV Rheinland-certified
17.3″ 16:9 Thin Bezel FHD 1920×1080, 300Hz, up to 100%sRGB, TÜV Rheinland-certified
17.3″ 16:9 Thin Bezel FHD 1920×1080, 144Hz, up to 100%sRGB, TÜV Rheinland-certified

System Memory

2x DDR5 slots (DDR5-4800, Max 64 GB)

Storage

2x M.2 SSD slots (Type 2280, supports 2x NVMe™ PCIe® Gen 4.0×4)
*The storage capacity may differ by country and region. Please contact your local dealers or retailers for the latest product information.**If there is any abnormality that cannot be attributed to Gigabyte/AORUS during the warranty period, it is not covered by the warranty. More info: https://member.aorus.com/global/productwarranty

Keyboard Type

Three-Zone RGB Keyboard, Per Key Macro

I/O Port

Left side :
1 x USB 3.2 Gen1 (Type-A)
1 x Audio combo Jack
1 x USB 3.2 Gen2 (Type-C)
Right Side :
2 x USB 3.2 Gen2 (Type-A)
1 x SD Card Reader
Rear side:
1 x Thunderbolt™ 4 (Type-C, support Power delivery)
1 x HDMI 2.1
1 x Mini DP 1.4
1 x RJ45
1 x DC in*Due to the performance laptops sometimes run with higher power consumption, we recommend the specification of the power adapter must be higher than 86W for the power delivery function to be practical.

Audio

2x 2W Speaker
Microphone
DTS:X® Ultra Audio Technology

Communications

WIFI: Wi-Fi 6E (802.11ax) (Triple band) 2×2
Bluetooth: Bluetooth® V5.2

Webcam

FHD (1080p ) Webcam
Build-in array Microphone
Support Windows Hello Face Authentication

Security

Firmware-based TPM, supports Intel® Platform Trust Technology (Intel® PTT)

Battery

Li Polymer 99Wh

Adapter

240W

Dimensions (W x D x H)

39.8(W) x 29.3(D) x 2.18(H) cm/ 15.7(W) x 11.5(D) x 0.86(H) inch

*The dimensions of the laptop may vary according to the configuration, manufacturing process and measurement method, please refer to the actual situation.

Weight

~2.8 kg
6.17 lb
*The weight of the laptop may vary according to the configuration, manufacturing process and measurement method, please refer to the actual situation.
